Description:

Type: Actuator

Model Number: AJS-10

Brand Name: NBSANMINSE

Name: AJS Valve Group for Bladder Accumulator

Type: Standard

Unloading: Manual

Nominal Pressure: 10 , 20 , 31.5 MPa

Structure: Direct over flow valve

Nominal Diameter: 10 mm

Accumulator Connector: M27X2,M42X2,M60X2,M72X2



General

AJ Application Valve Group for Accumulator . Which consists of stopping valve ,

Protection valve unloading valve , etc . Is set between accumulator and hydraulic system to control the oil condition of make – and break , overflow and unloading ( which consists of manual and electromagnetic ) .



Gode Name : Application Valve Group For Accumulator

Standard

Unloading Type : S – Manual ( Standard )

Nominal Diameter : 10 , 20 , 32mm

Pressure Of Protection Valve :

a-6.3MPa , b-16MPa , c-25MPa , h-31.5MPa

Z – Direct Over Flow Valve

Thread of Accumulator Connector :

M27 X 2 , M42 X 2 , M60 X 2 , M72 X 2





​
